The RB-01 BGA Reballing Stencil Tin Net Full Set is a comprehensive reballing solution designed for EMMC, EMCP, and UFS chip repair and rework. This high-precision stencil set is essential for professional repair technicians, electronics engineers, and microsoldering experts working on smartphone, tablet, and other digital device motherboards. RB-01 BGA Reballing Stencil
Made from high-quality stainless steel, this stencil set ensures long-lasting durability, high heat resistance, and accurate tin placement, making it an ideal choice for BGA chip soldering and rework. With its precise laser-cut holes and universal compatibility, it provides stable and reliable results for EMMC, EMCP, and UFS IC chip reballing. RB-01 BGA Reballing Stencil
Whether you’re restoring faulty chips, replacing damaged ICs, or reworking mobile motherboards, the RB-01 BGA Reballing Stencil Tin Net Full Set ensures high success rates and professional-grade repairs. RB-01 BGA Reballing Stencil
Key Features of the RB-01 BGA Reballing Stencil Tin Net Full Set
1. Universal Compatibility for EMMC, EMCP, and UFS ICs
Supports a wide range of chip sizes and configurations for universal use.
Compatible with smartphones, tablets, laptops, and other digital devices.
Ideal for chip-level repair on various motherboard types.
2. High-Quality Stainless Steel Construction
Made from premium stainless steel for high durability and long lifespan.
Resistant to corrosion, bending, and deformation even under extreme heat.
Provides consistent and reliable performance for repeated use.
3. Ultra-Precision Laser-Cut Holes for Accurate Reballing
Features precisely laser-etched apertures for uniform tin distribution.
Reduces the risk of solder bridging, misalignment, and weak joints.
Ensures clean and precise solder paste application, improving repair quality.
4. High Heat Resistance for Professional Soldering Work
Withstands high soldering temperatures, making it compatible with hot air rework stations and infrared heating.
Maintains its shape and precision even under extreme heat conditions.
5. Comprehensive Full Set for Various Chip Sizes
Includes multiple stencil sizes and configurations, covering different chip layouts.
Allows technicians to work on a variety of BGA chips with a single kit.
6. Thin & Flexible Design for Precise Alignment
The ultra-thin structure ensures perfect positioning over IC chips.
Allows tight fit over components, improving solder paste or tin ball application accuracy.
7. Professional-Grade Repair Tool for Microsoldering Technicians
Designed for BGA chip reballing, motherboard repairs, and IC chip rework.
Suitable for use in repair labs, service centers, and mobile phone refurbishment workshops.
Why Choose the RB-01 BGA Reballing Stencil Tin Net Full Set?
✅ Universal Compatibility – Supports EMMC, EMCP, and UFS IC chips, making it a versatile repair tool.
✅ Ultra-Precise Laser-Cut Holes – Ensures accurate tin placement, preventing soldering errors.
✅ Premium Stainless Steel Material – Offers long-lasting durability and high heat resistance.
✅ Flexible & Thin for Precise Alignment – Provides better control and accuracy during reballing work.
✅ Essential for Professional Repair Technicians – A must-have tool for IC rework, BGA chip soldering, and motherboard repair.
Applications of the RB-01 BGA Reballing Stencil Tin Net Full Set
✔ EMMC, EMCP, and UFS Chip Reballing – Ensures precise tin application for chip repair and replacement. ✔ BGA IC Chip Repair & Rework – Ideal for restoring faulty or detached IC chips. ✔ Motherboard-Level Soldering Work – Supports professional microsoldering tasks on smartphone and tablet logic boards. RB-01 BGA Reballing Stencil ✔ Professional Electronics Repair – Used in repair labs, service centers, and BGA chip refurbishment workshops. RB-01 BGA Reballing Stencil
How to Use the RB-01 BGA Reballing Stencil for Best Results?
1. Prepare the Work Area
Set up a clean, well-lit, and ESD-safe workspace.
Use a microscope or magnifying lens for detailed soldering work.
2. Secure the Stencil & Align the IC Chip
Place the target EMMC, EMCP, or UFS chip on a heat-resistant mat.
Position the appropriate stencil over the chip, ensuring proper alignment with contact pads.
3. Apply Solder Paste or Tin Balls
Spread an even layer of solder paste using a squeegee to fill the stencil holes.
If using tin balls, carefully place them into the apertures using tweezers.
4. Heat & Reflow the Solder
Use a hot air rework station (300-350°C) to melt and reflow the solder paste.
Ensure even heating to prevent uneven solder joints.
5. Remove the Stencil & Inspect the Solder Joints
Allow the solder to cool and solidify, then carefully lift the stencil.
Inspect the reballing results under a microscope to ensure clean, uniform solder joints.
6. Attach the IC Chip to the Motherboard
Once reballing is complete, reinstall the IC chip onto the device motherboard.
Apply controlled heat to secure the chip in place.
Technical Specifications
Brand: RB-01
Model: BGA Reballing Stencil Tin Net Full Set
Compatibility: EMMC, EMCP, and UFS IC chips
Material: High-Quality Stainless Steel
Thickness: Ultra-thin for precise solder application
Hole Type: Laser-cut apertures for accurate tin placement
Heat Resistance: High-temperature resistant, suitable for hot air and infrared rework stations
Conclusion
The RB-01 BGA Reballing Stencil Tin Net Full Set is an indispensable tool for professional microsoldering technicians specializing in BGA chip repair and rework. With its high-precision laser-cut holes, durable stainless steel construction, and universal compatibility, this stencil set ensures flawless IC chip reballing and accurate tin placement. RB-01 BGA Reballing Stencil
Whether you’re repairing EMMC, EMCP, or UFS chips, reballing smartphone motherboards, or restoring complex IC components, this stencil set provides exceptional accuracy and reliability. RB-01 BGA Reballing Stencil
Upgrade your BGA reballing toolkit today with the RB-01 Stencil Set and achieve perfectly reballed IC chips with ease! RB-01 BGA Reballing Stencil
