Please read the manual before use.
This section sets the foundation for a safe repair environment. Before a single tool touches a phone, the workspace must be prepared to protect both the technician and the sensitive electronics.
Electrostatic Discharge (ESD) Safety: Instructions on grounding yourself using an ESD wrist strap and working on an anti-static mat to prevent frying microchips with static electricity.
Safety Gear: Protocols for wearing safety glasses (critical when prying shattered glass) and working in a well-ventilated area (crucial for adhesive fumes and soldering smoke).
Lighting and Magnification: Recommendations for high-intensity desk lamps and digital microscopes or magnifying visors for viewing microscopic components.
The most physically risky part of mobile repair is opening the device without cracking the glass screen or ripping delicate internal ribbon cables.
Thermal Tools (Heat Guns & Heat Pads): Instructions on setting precise temperatures (typically 80°C to 100°C) to soften heavy factory adhesives without damaging the display.
Suction & Leverage Tools: Proper placement of heavy-duty suction cups and screen prying fixtures to safely create an initial gap.
Separation Media (Plastic Picks & Spudgers): Techniques for slicing through glue lines using plastic opening picks without inserting them too deeply into the frame.
Modern smartphones use dozens of tiny, highly specialized screws and brackets to hold internal shields in place.
Precision Driver Identification: A breakdown of specialized micro-bits, detailing exactly when to use Pentalobe (iPhones), Tri-point/Y-type (internal Apple shields), Torx/Torx Security (Android devices), and standard Micro-Phillips.
Organization Systems: Guidelines for using magnetic project mats or screw organizing trays to map out screw locations, preventing the catastrophic error of “long-screw damage.”
Gripping & Placer Tools: How to utilize straight and curved ESD-safe tweezers to safely disconnect fragile ZIF (Zero Insertion Force) and coaxial cable connectors.
This section transitions the user from basic mechanical teardowns to logical troubleshooting when a phone won’t turn on or charge.
Digital Multimeter (DMM): Step-by-step instructions on setting up the meter for DC voltage testing (checking battery and charging port output) and continuity/diode mode (hunting for short circuits).
DC Power Supply: How to boot a phone motherboard without a battery attached, interpreting current draw (Amperage) to diagnose power management failures.
USB Ammeter / Tester: Utilizing an inline USB safety tester plugged into the charging block to instantly diagnose if a phone is pulling normal current ($1A$ to $2A$) or completely dead ($0A$).
For advanced users handling board-level fixes like swapping out charging ports, audio IC chips, or FPC connectors.
Soldering Iron Stations: Temperature calibration tips, tip selection (chisel vs. conical), and maintenance/tinning procedures.
Hot Air Rework Stations: Managing the delicate balance of air flow and temperature to safely desolder multi-pin components without blowing adjacent surface-mount resistors off the board.
Chemical Consumables: Proper application of rosin flux (to clean joints and fluidize solder), solder wick (braided wire to remove old solder), and low-melt solder alloys.
The final step is cleaning up the internal cavity and sealing the device back up to its original structural integrity.
Chemical Cleaners: Safe usage of 99% Isopropyl Alcohol (IPA) to dissolve old glue residues, flux oils, and clean mild liquid damage.
Liquid Adhesives vs. Tape: Instructions on applying specialized acrylic glues (like B-7000) versus applying precision-cut double-sided adhesive gaskets.
Camping and Curing: Utilizing specialized display repair clamps to apply even, steady pressure while the new adhesives cure over 15 to 30 minutes.
Introducing the BG TOOLS three-force bearing motherboard fixtures with high strength carbon fiber board, the ultimate solution for precision and durability. Crafted with cutting-edge high-strength carbon fiber material, these fixtures provide unyielding support for your motherboard, ensuring maximum stability during high-performance operations.
The robust carbon fiber board construction is not only lightweight but also resistant to stress, deformation, and wear. Perfect for professionals and hobbyists alike, these fixtures are designed to withstand demanding applications, maintaining their integrity over extended use while safeguarding your devices.
BG TOOLS three-force bearing fixtures feature an intuitive design that allows for seamless installation. Whether you’re upgrading existing hardware or working on complex assembly tasks, this innovative product delivers unmatched functionality and reliability, making it a must-have tool for your workstation.
The BG TOOLS Three-Force Bearing Motherboard Fixture is an elite-grade, professional hardware repair station engineered specifically for micro-soldering, IC reballing, and heavy-duty logic board maintenance. Built utilizing an ultra-durable composite high-strength carbon fiber board, this fixture introduces a proprietary “Three-Force” bearing structural clamping dynamic.
Unlike traditional aluminum or synthetic glass fixtures that warp under consistent high-temperature exposure, this tool offers peerless thermal insulation and mechanical structural stability, making it an essential asset for advanced smartphone, tablet, and MacBook repair technicians.
Standard PCB holders use single or dual parallel clamping jaws that distribute force unidirectionally. When a technician applies downward scraping or prying force during chip desoldering, the motherboard can flex or pop out of its track.
The BG TOOLS three-force bearing structure changes this dynamic completely by creating an equidistant pressure triangle.
The Axial Force: Pushes the PCB firmly along the $X$-axis via the main adjustment knobs.
The Lateral Retention Force: Locks the board into custom step-grooves, mitigating any $Y$-axis lateral shifting.
The Vertical Counter-Force: Driven by specialized integrated bearings situated within the sliding blocks. These absorb the downward mechanical energy from a technician’s tweezers, scraping blades, or dental picks, completely neutralizing board flex and preventing micro-fractures in buried PCB traces.
The integration of a genuine high-strength carbon fiber plate elevates this fixture beyond standard repair jigs. The carbon fiber surface combined with a glass fiber substrate yields unique properties:
Zero Heat-Sinking Deflection: Aluminum alloy fixtures act as giant heat sinks. When you blow $380^circtext{C}$ hot air onto a CPU, the metal base pulls that heat away, forcing you to turn your rework station up to dangerous levels ($420^circtext{C}+$) which can easily delaminate the PCB. The BG TOOLS carbon fiber composition restricts heat absorption. The heat stays localized in the silicon die, allowing you to safely desolder massive ICs at much lower air temperatures.
Furthermore, carbon fiber remains cool to the touch immediately adjacent to the work area, facilitating faster bench turnarounds without burnt fingers.
The fixture jaws are cut using ultra-precise CNC mills to create specialized stepped profiles.
The Upper Step: Designed explicitly to bite onto the ultra-thin $0.4text{ mm}$ perimeter rails of modern multi-layered stacked motherboards (e.g., iPhone sandwich boards) without crushing delicate components or surface-mount capacitors sitting near the edge.
The Lower Step / V-Groove: Dedicated to gripping irregular shapes, chips, and square IC packages (such as NAND Flash, power management ICs, and CPUs) for clean adhesive removal and manual reballing.
Over time, flux overspray, isopropyl alcohol (IPA), rosin cleaners, and UV-curable solder masks destroy typical plastic or resin-coated fixtures.
The high-modulus carbon fiber board used by BG TOOLS is chemically inert to professional electronics maintenance solvents. Carbon fiber resists scraping from hardened steel blades, maintaining a flawlessly flat surface plane over years of daily bench use. The custom-engineered internal lead screws run seamlessly on sealed bearings that block out stray solder balls, dust, and scorched rosin flakes.
